P-640-J
ESD ELASTOMER TIP TWEEZERS

Material Tip Polypropylene + Elastomer
Body Stainless（SUS420J2）
Color Black+gray
ESD standard 1×104≦Rg<1×1012Ω
Weight 17g
Replacement parts P-640J-1







Replacement parts

P-640-0
MOUNTING SCREWS

Quantity: 50 sets (50 screws, 50 nuts)



ESD Tip / Plastic Tip / Tweezers Tip

ESD-SAFE：ESD Elastomer Tip,ESD Tip

CORROSION-RESISTANCE：P-643N-1 / P-645N-1



Part. no Product Name  size Material Color Heat resistant temp.℃ ESD standard Ω Quantity
A B Tip width
P-640J-1 ESD ELASTOMER
TIP		 48 10 1.5 Polypropylene + Elastomer Black+ gray - 1×104≦Rp<1×1012 2-piece set
P-643J-1 3.0 (R-type）
P-645J-1 6.0 (R-type）
P-640S-1 ESD
Tip		 1.2 PEEK*1 Black 315
P-641S-1 0.4
P-642S-1 1.0 (R-type）
P-643S-1 47 2.4 (R-type）
P-644S-1 48 0.6
P-645S-1 6.0
P-640P-1 Plastic
Tip		 1.2 PBT*2 White - -
P-644P-1 0.6
P-643N-1 Non-Stick
Tip		 46 2.4 (R-type HDPE*3 White
(Translucent)		 - -
P-645N-1 48 6.0



For P-640 to 650 series

*1 PEEK (polyether ether ketone) is an engineering plastic that has particularly good mechanical properties and heat resistance.

*2 PBT（poly butylene terephthalate）is an engineering plastic that has particularly good mechanical properties and heat resistance.

*3 HDPE：High Density Polyethylene.
